About your monitor | 9
Back view
Back view without monitor stand
Back view with monitor stand
Label Description Use
1 Joystick Use it to control the OSD menu.
2 Function buttons For more information, see Operating
the monitor.
3 Barcode, serial number, and
Service Tag
label
Refer to this label if you need to
contact Dell for technical support.
4 Cable-management clip To organize the cables neatly.
5 Stand release button Releases stand from the monitor.
6 VESA mounting holes (100 mm
x 100 mm - behi
nd VESA
Cover)
Wall mount monitor using VESA-
compatible wall mount kit (100 mm x
100 mm).
7 Regulatory label Lists the regulatory approvals.
