Alienware AW3420DW - Rear and Bottom Ports

10 | About your monitor
Rear and bottom view
Rear and bottom view without monitor stand
8 Lighting dock connector When the stand riser is attached to the
m
onitor, the dock supplies power to
the light on the stand.
9 Cable-management slot (at the
ba
ck of the stand)
To organize cables by routing them
through this slot.
10 I/O cover Protects the I/O ports.
Label Description Use
1 Power connector Connect the power cable (s
hipped with your
monitor).
2 Line-out port Connect your speakers.
NOTE: Th
is port does not support
headphones.
3 HDMI port Connect your computer with an HDMI cable
(s
old separately).
4 DisplayPort Connect your computer with
DisplayPort-
DisplayPort or Mini-DisplayPort-DisplayPort
cable (shipped with your monitor).
