Alienware M14X User Manual

CHAPTER 4: INSTALLING AND REPLACING COMPONENTS
73
To replace the battery pack:
Follow the the instructions in “Before You Begin” on page 1. 66.
Place the battery pack in the battery bay and tighten the two captive screws that secure 2.
the battery pack to the computer base.
Connect the battery pack cable to the connector on the system board.3.
Align the tabs on the base cover with the slots on the computer base.4.
Slide the base cover until it clicks into place. 5.
Tighten the two captive screws that secure the base cover to the computer base.6.

Alienware M14X Specifications

General

Storage	Up to 750GB HDD or 256GB SSD
Weight	6.45 lbs (2.93 kg)
Display	14.0 inch (1600 x 900) WLED
RAM	Up to 8GB DDR3
Operating System	Windows 7 Home Premium
Battery	8-cell Lithium Ion
Dimensions	1.49 (inches)
