Alienware M14X User Manual

CHAPTER 4: INSTALLING AND REPLACING COMPONENTS
75
Removing the Memory Module(s)
Follow the instructions in “Before You Begin” on page 1. 66.
Shut down the laptop and turn it over.2.
Loosen the two captive screws that secure the base cover to the computer base.3.
Slide and lift the base cover o the computer base.4.
Remove the battery (see “Replacing the Battery Pack” on page 5. 70).
Loosen the two captive screws that secure the memory‑module cover to the computer 6.
base.
Lift the memory‑module cover away from the computer.7.

Alienware M14X Specifications

General

Storage	Up to 750GB HDD or 256GB SSD
Weight	6.45 lbs (2.93 kg)
Display	14.0 inch (1600 x 900) WLED
RAM	Up to 8GB DDR3
Operating System	Windows 7 Home Premium
Battery	8-cell Lithium Ion
Dimensions	1.49 (inches)
