ALKOTA 2142 - Burner & Gun Parts Lists; Burner Parts List; Burner Gun Parts List

Item Part No. Description
1 V00-12701 Screw, Thread Cutting
2
V00-
20627
Motor, Electric – 115V
3
V00-
13121
Strain Relief, Cord
4 H04-19000 Screw, Thread Cutting
5 V00-13073 Cover, Junction Box
6 H04-16404 Screw, Thread Cutting
7 V00-21319 J-Box
8 V00-12699 Screw, Machine
9
V-101121-001
Ignitor
10
V-30537-003
Assembly, Burner Gun
11 V00-13392 Cover, Slot
12 V00-14296 Nut, Hex
13 V00-13424 Coupling, Shaft
14 V00-14283 Pump, Fuel
15
V-20602-002
Band, Outer
16
V-20601-002
Band, Inner
17 V00-14157 Cone, Air - #1A
18 V00-12484 Gasket, Flange
19 V00-14116 Screw, Machine
20 H04-31302 Screw, Set
21 V00-21427 Fan w/ Item 27
22
V00-14451-1
Assembly, Oil Line
*22 V00-14451 Assembly, Oil Line
*23 F04-00310 Connector, Conduit
*24 F05-10310 Conduit, Electrical)
*25 F04-00974 Solenoid, Oil
*26
V00-13064-1
Connector, Flare
27 ---------------
Nozzle – See Burner
Ass’y
*18 Item used on V00-173173 oil line to Fuel pump
Item Part No. Description
1 V-100772-001 Assembly, Electrode – RH
*1A --- Stem, Electrode – RH
1B V00-12574 Insulator, Electrode
1C V00-100004-1 Bar, Buss – Straight
1D V00-13110 Nut, Pal
2 V00-12408 Bushing, Insulator
3 V00-12694 Screw, machine
4 H04-19002 Screw, Set
5 V00-12695 Screw, Machine
6 V-21410-002 Assembly, Oil Pipe
7 V-100773-001 Assembly, Electrode – LH
*7A --- Stem, Electrode – LH
7B V00-12574 Insulator, Electrode
7C V00-100004-1 Bar, Buss – Straight
7D V00-13110 Nut, Pal
8 V00-13409 Plate, Bafe – 2 1/2”
9 V00-14310 Support, Electrode
10 V00-14442 Spring, Electrode Support
11 V00-13411 Screw, Thread Cutting
12 V00-12362 Adapter, Nozzle
13 V1.75 90DA Nozzle. Burner
Burner Breakdown Parts List
p/n V00-173133, V00-173173
Burner Gun Breakdown Parts List
p/n V00-30537-006
