3. Fuel burning equipment must have proper ven-
tilation for cooling, combustion air, and ex-
hausting of combustion products.
4. Stacking, where required, must be installed in
accordance with all local codes. A draft diverter
must be installed on a machine connected to
an exhaust stack to prevent improper opera-
tion.
5. Where stacking is not required, provide adequate
ventilations to prevent any possible accumula-
tion of hazardous fumes.
6. Personnel trained in and familiar with the type
of equipment being serviced should only per-
form adjustments to fuel burning equipment.
SAVE THESE SAFETY
INSTRUCTIONS
INSTALLATION
1. LOCATION: This machine should be
installed by only qualified technicians. The
machine should be set upon a level surface
where it will not be affected by strong winds,
rain, snow, extreme heat, and freezing
temperatures. Install the machine
considering locations for chemical pick-up, fuel
connections, electrical connections, water
hook-up, venting, and maintenance.
All wiring and electrical connections should
comply with the National Electrical Code (NEC)
and with local codes and practices. Use the
chart on the next page for your cord selection
2. ELECTRICAL: Connect machine to an
electrically grounded circuit that is fused or
circuit breaker protected. The circuit must
match that specified in the ELECTRICAL
section under MODEL SPECIFICATION
3. EXTENSION CORD: The use of an extension
cord that has undersize wire compared to the
amp draw of your machine will adversely limit
the starting load carrying abilities of the motor
and machines performance. Use only 3-wire
extension cords that have 3-prong plugs and
3-pole cord connectors that accept the plug
from the product. Use only extension cords
that are intended for outdoor use. These
extension cords are identified by a marking
“Acceptable for use with outdoor appliances;
store indoors while not in use.” Use only
extension cords having an electrical rating not
less than the rating of the product. Do not use
damaged extension cords. Use an extension
cord in good repair free of frays or cracks in
the outer covering. Do not abuse extension
cord and do not yank on any cord to disconnect.
Keep cord away from heat and sharp edges.
Always disconnect the extension cord from the
receptacle before disconnecting the product
from the extension cord.
WARNING: To reduce the risk of electrocution,
keep all connections dry and off the ground.
Do not touch plug with wet hands.
CHART FIGURES ARE BASED ON NOT
MORE THAN 100 FOOT
(Based on Ambient Temperature of 86°F (30°C)).
*Use Amp Draw indicated the same or higher than
your machine output
EXAMPLE: Machine Amp Draw 51, use 55 (2
Conductor). The thermostat type of cord shall be
C, PD, E, EO, EN, S, SO, SRD, SJ, SJO, SV, SVO,
SP.
The thermoset plastic types shall be ET, ETT, ETLB,
ETP, ST, STO, SRDT, SJT, SJTO, SVT, SVTO, and
SPT.
COPPER
WIRE SIZE
MINIMUM
AWG
MACHINE AMP
DRAW*
3 CONDUCTOR
WIRES
MACHINE AMP
DRAW*
2 CONDUCTOR
WIRES
16 10 13
15 -- --
14 15 18
12 20 25
10 25 30
8 35 40
6 45 55
4 60 70
2 80 95
WARNING: ELECTRICAL SHOCK
HAZARD
5
ECN-02981Supersedes 09-00 Z08-02832
To Next Page
