11-21-03 Z08-00481B
ELECTRICAL INSTALLATION
1.ELECTRICAL: Connect machine to an
electrically grounded circuit that is fused or
circuit breaker protected. The circuit must match
that specified in the ELECTRICAL section under
MODEL SPECIFICATIONS.
CHART FIGURES ARE BASED ON NOT
MORE THAN 100 FOOT
(Based on Ambient Temperature of 86°F (30°C)).
*Use Amp Draw indicated the same or higher than
your machine output
EXAMPLE: Machine Amp Draw 51, use 55 (2
Conductor). The thermostat type of cord shall be
C, PD, E, EO, EN, S, SO, SRD, SJ, SJO, SV, SVO,
SP.
The thermoset plastic types shall be ET, ETT, ETLB,
ETP, ST, STO, SRDT, SJT, SJTO, SVT, SVTO, and
SPT.
2. EXTENSION CORD: The use of an extension
cord that has undersize wire compared to the
amp draw of your machine will adversely limit
the starting load carrying abilities of the motor
and machines performance. Use only 3-wire
extension cords that have 3-prong plugs and
3-pole cord connectors that accept the plug
from the product. Use only extension cords
that are intended for outdoor use. These
extension cords are identified by a marking
“Acceptable for use with outdoor appliances;
store indoors while not in use.” Use only
extension cords having an electrical rating not
less than the rating of the product. Do not use
damaged extension cords. Use an extension
cord in good repair free of frays or cracks in
the outer covering. Do not abuse extension
cord and do not yank on any cord to disconnect.
Keep cord away from heat and sharp edges.
Always disconnect the extension cord from the
receptacle before disconnecting the product
from the extension cord.
WARNING: To reduce the risk of electrocution,
keep all connections dry and off the ground.
Do not touch plug with wet hands
OPERATING
INSTRUCTIONS
PRE START-UP
1. The first time the machine is operated, after
repairs have been made, or if the machine has
set for a period of time (30 days or more) follow
the following procedures.
A. Check the tension of the belt (if so
equipped) per instructions in MACHINE
MAINTENANCE.
B. Flush the machine per instructions in
MACHINE MAINTENANCE.
C. Install float tank drain plug (if so equipped).
D. Open float tank ball valve (if so equipped).
♦ CAUTION: Always use the factory supplied
pressure wash hose with your machine.
♦ DO NOT substitute any other hoses as a
potential safety problem may develop.
¨ CAUTION: If machine has been exposed to
sub-freezing temperatures, it must be
thoroughly warmed to above freezing before
operating. Failure to warm machine can cause
damage to the pump packings and other
components.
2. Read and observe all items in “CLEANER
INSTALLATION”.
START-UP
♦ Refer to the MAINTENANCE SCHEDULE for
any maintenance to be performed before
operation.
5
ECN-03022Supersedes 02-12-01 Z08-00481B
WARNING: ELECTRICAL SHOCK
HAZARD
COPPER
WIRE SIZE
MINIMUM
AWG
MACHINE AMP
DRAW*
3 CONDUCTOR
WIRES
MACHINE AMP
DRAW*
2 CONDUCTOR
WIRES
16 10 13
15 -- --
14 15 18
12 20 25
10 25 30
8 35 40
6 45 55
4 60 70
2 80 95
