ALLEN & HEATH ML5000 User Guide

20 ML5000 User Guide
CONTROL LAYOUT
A MONO INPUT and EQ
B GRP/AUX SENDS
C MAIN MIX SENDS
D INPUT FADERS
E STEREO INPUT and EQ
F GRP/AUX 1-8 MASTERS
G AUX 9-16 MASTERS
H ROTARY AUX 1-8 MASTERS
I MAIN MIX FADERS
J MATRIX
K VCA GROUPS
L MUTE GROUPS
M SNAPSHOT MEMORIES
N SOLO-IN-PLACE
O HEADPHONES / MONITOR
P PAFL CONTROL
Q OSC/NOISE GENERATOR
R INTERCOM
S TALKBACK
T GRP/AUX 1-8 METERS
U LRC/PAFL METERS
V AUX 9-16 / MTX 1-8 METERS
