ALLEN & HEATH Qu-24 User Manual

Qu Mixer User Guide 4 AP9372 iss.4
1. Packed contents
Options and Accessories available
Qu Mixer
Safety Sheets
AP3345 – English
AP7287 – French
AP8513 – Chinese
• Read this before starting
Mains lead • Check this
is correct for your territory
User Guide
A
P9372
REGISTER YOUR PRODUCT online at: http://www.allen-heath.com
Qu-Pad app for iPad
Available from the Apple Store
LEDlamp
Right angled 4-pin XLR
LED lamp with built-in
dimmer
Part: LEDlampX
Remote Audio Racks
Provides remote audio over dSNAKE Cat5 cable digital snake.
AR2412 24 Mic/Line in, 12 Line out AR84 8 Mic/Line in, 4 Line out
Part: GLD-AR2412 Part: GLD-AR0804
19” Rack Ear Kit for Qu-16
To mount the Qu-16 in a standard 19” rack or
flightcase. These fit over the plastic trims.
Part: QU-16-RK19
AB168 16 Mic/Line in,
8 Line out Remote
AudioRack.
Part: AB1608
Soft cover
AP9262 Qu-16
AP9458 Qu-24
AP9639 Qu-32
Qu
Cat5 cables
For use with dSNAKE remote
audio
AH8822 2m (6.6’) short patch
AH9651 20m (66’) coil
AH9650 100m (330’) drum

ALLEN & HEATH Qu-24 Specifications

General

Type	Digital Mixer
Channels	24
Faders	25
Mix Busses	10
FX Engines	4
USB Audio Interface	32x32
Touchscreen	Yes
Frequency Response	20Hz to 20kHz (+0/-0.5dB)
Sampling Rate	48kHz
EQ Bands	4-band Parametric
Computer Connectivity	USB, Ethernet
USB	Yes
Word Clock	No
Dynamic Processing	Gate, Compressor, Limiter
Built-in WiFi	No
Power Supply	Internal
Inputs - Mic Preamps	24
Outputs - Main	2
Outputs - Aux	10
Headphones	1/4-inch stereo
I/O Expansion Slots	dSnake
