Diagnostics
A number of LEDs are placed on the main CPU, Fader board, DSP-FX
board and I/O cards to help monitor activity on these boards. This
includes LEDs for power rails, high speed link, and FPGA/DSP
programmed and active.
The Blue LED on the rear of the unit should be static.
Due to the presence of these LEDs, there are less needs for power
rail test points.
Also supplied are routing overviews for Power Distribution and
Control/Audio routing. Use these to identify an associated PCB
when a fault occurs.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ALLEN & HEATH SQ and is the answer not in the manual?

ALLEN & HEATH SQ Specifications

General IconGeneral
TypeDigital Mixer
Channels48
Effects8 stereo FX engines
TalkbackYes
Sampling Rate96kHz
Expandable ChannelsUp to 48 local + 48 remote
Local Outputs16
Digital OutputsAES3
EQ Bands4-band parametric
Effects Racks4
ConnectivityEthernet, USB
USB Audio Interface32x32
Built-in InterfacesSLink
Screen7-inch touchscreen
SoftwareSQ MixPad
Power SupplyInternal
Weight10.5 kg
