Fader Board LEDs
1
2
3
1. Active = Processor Active Yellow LED. Displays heart beat pattern. Two (2) present on SQ6. The
processor is powered by the +3V3 rail, if this LED is off, there is likely an issue with the +3V3 rail.
2. +3V3 rail Yellow LED. On Solid = Good (SQ5 Only)
3. +5V Fader Motor power good indicator Green LED. On Solid = Power Good

ALLEN & HEATH SQ Specifications

General

Type	Digital Mixer
Channels	48
Effects	8 stereo FX engines
Talkback	Yes
Sampling Rate	96kHz
Expandable Channels	Up to 48 local + 48 remote
Local Outputs	16
Digital Outputs	AES3
EQ Bands	4-band parametric
Effects Racks	4
Connectivity	Ethernet, USB
USB Audio Interface	32x32
Built-in Interfaces	SLink
Screen	7-inch touchscreen
Software	SQ MixPad
Power Supply	Internal
Weight	10.5 kg
