Allen & Heath 3 XB-14 User Guide
Limited One Year Warranty
This product is warranted to be free from defects in materials or
workmanship for period of one year from the date of purchase by the
original owner.
To ensure a high level of performance and reliability for which this
equipment has been designed and manufactured, read this User Guide
before operating. In the event of a failure, notify and return the
defective unit to ALLEN & HEATH Limited or its authorised agent as
soon as possible for repair under warranty subject to the following
conditions
Conditions Of Warranty
The equipment has been installed and operated in accordance with the
instructions in this User Guide.
The equipment has not been subject to misuse either intended or
accidental, neglect, or alteration other than as described in the User
Guide or Service Manual, or approved by ALLEN & HEATH.
Any necessary adjustment, alteration or repair has been carried out by
ALLEN & HEATH or its authorised agent.
This warranty does not cover fader wear and tear.
The defective unit is to be returned carriage prepaid to ALLEN &
HEATH or its authorised agent with proof of purchase.
Units returned should be packed to avoid transit damage.
In certain territories the terms may vary. Check with your ALLEN &
HEATH agent for any additional warranty which may apply.
This product complies with the European Electro magnetic Compatibility
directives 89/336/EEC & 92/31/EEC and the European Low Voltage
Directives 73/23/EEC & 93/68/EEC.
This product has been tested to EN55103 Parts 1 & 2 1996 for use in
Environments E1, E2, E3, and E4 to demonstrate compliance with the
protection requirements in the European EMC directive 89/336/EEC.
During some tests the specified performance figures of the product were
affected. This is considered permissible and the product has been passed as
acceptable for its intended use. Allen & Heath has a strict policy of
ensuring all products are tested to the latest safety and EMC standards.
Customers requiring more information about EMC and safety issues can
contact Allen & Heath.
Allen & Heath XB-14 User Guide AP7506 Issue 3
Copyright © 2007 Allen & Heath Limited. All rights reserved
Allen & Heath Limited
Kernick Industrial Estate, Penryn, Cornwall, TR10 9LU, UK
http://www.allen-heath.com

Other manuals for ALLEN & HEATH XB-14

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ALLEN & HEATH XB-14 and is the answer not in the manual?

ALLEN & HEATH XB-14 Specifications

Operating Levels IconOperating Levels
Mono channel Mic input range+6 to –63dBu
Mono channel Line input range+10 to –26dBu
Insert point nominal level0dBu
Stereo input nominal level0dBu
Telco channel input range+10 to –26dBu
External monitor inputs nominal level0dBu
Output Levels IconOutput Levels
PGM L & R outputs nominal level+4dBu
PGM Mono output nominal level0dBu
PGM L & R inserts nominal level-2dBu
Aux output nominal level0dBu
Mix B outputs nominal level0dBu
Rec outputs nominal level0dBu
Audio Performance IconAudio Performance
THD+n Mic in to PGM L/R Out0.003%
THD+n Mic in to PGM Out0.007%
THD+n Line in to PGM L/R out0.004%
THD+n Stereo in to PGM out0.003%
Noise Mic Pre EIN-127dBu
Noise PGM out-92dBu
Frequency Response IconFrequency Response
Mic in to PGM L/R Out20Hz to 20kHz
Line in to PGM L/R out10Hz to 30kHz
Stereo in to PGM L/R out10Hz to 30kHz
Headroom IconHeadroom
Analogue Headroom Outputs21dB
USB in & out headroom14dB
Analogue Headroom Mix point24dB
Crosstalk & Attenuation IconCrosstalk & Attenuation
Mono fader attenuation 1kHz/10kHz-99/-90
Mono ON switch attenuation 1kHz/10kHz-96/-80
TELCO fader attenuation 1kHz/10kHz-99/-92
TELCO ON switch attenuation 1kHz/10kHz-102/-100
Stereo fader attenuation 1kHz/10kHz-100/-91
Stereo ON switch attenuation 1kHz/10kHz-102/-102
