ALLEN & HEATH XONE 92 Service Manual

XONE:92 PSU IEC Mains Filter with Nutserts
ECN No: 998
Assembly No(s): 003-233, Issue 1 on
Date: March 29
th
2004
Reason: To improve assembly of IEC to Chassis.
Details of change:
The IEC Mains Filter AL3458 now has nutserts, eliminating the need to fit two
nyloc nuts (AB0102), and two screws (AB0078).
The new screws required are AB5564 x 2 (under head pips):
This change was applied to issue 1 PCBs onwards from March 2004.
ECN 998

ALLEN & HEATH XONE 92 Specifications

General

Type	Analog
LFO	No
Record Output	RCA
Filters	2 VCF filters
Inputs	4 phono, 4 line, 2 mic
Outputs	Master, Booth, Record, Headphone
Aux Sends	2 aux sends
Mic Inputs	2
Master Output	XLR
Booth Output	1/4" Jack
Headphone Output	1/4" Jack and 3.5mm Jack
MIDI	MIDI out
Crossfader	VCA crossfader
Effects	No built-in effects
Power Supply	Internal
Dimensions	320mm x 358mm x 88mm
