XONE:92 Slave PCB capacitor change
ECN No: 1020
Assembly No(s): 003-141, Issue 1
Date: May 17
th
2004
Reason: Easier to select multiple channel cues.
Details of change:
CAPACITOR VALUE CHANGE Assy 003-141, PCB AG5303 iss.1
Change capacitor C17 from 1/63 (AF0210) to 10/50 (AF0214)
This capacitor was fitted to issue 1 PCBs from serial no 063515 until the
introduction of the issue 2 PCBs.
ECN 1020
