Assembly data
Production Line
Xone
Product
PX5
Assembly Stage
Final assembly
Issue Date
12/07/16
Revision Number
ISSUE 1
AH-M0773
30. AA9076 BRACKET XONE: 23/23C XFDR AND CROSSFADER PCBA FROM THE MAIN PCBA.
31. MOUNT THE BRACKET ONTO THE CROSSFADER AND SECURE USING AB9037 SCREW
M3X4 TRUNC x2.
32. INSPECT FOR DEFECTS AA10187 FRONT PANEL XONE: PX5.
