Assembly data
Production Line
Xone
Product
PX5
Assembly Stage
Final assembly
Issue Date
12/07/16
Revision Number
ISSUE 1
AH-M0773
33. FIT DOUBLE SIDED TAPE x3 PIECES TO THE INSIDE EDGE OF THE HOLE FOR THE SCREEN
AS SHOWN.
34. AA10183 FACIA ACRYL XONE: PX5 TFT.
35. STICK THE FACIA TO THE FRONT PANEL TAKING NOTE OF THE ORIENTATION.
36. FIT PROTECTIVE FILM OVER THE TOP OF THE FACIA ONCE FITTED TO THE FRONT
PANEL.
