ALLEN & HEATH ZED 420

Allen & Heath 33 ZED-4 BUS User Guide
WIRING NOTES
GROUND
RETURN
SEND
RETURN
OUT
IN
SEND
INSERT
PROCESSOR
LINK RING TO SLEEVE TO UNBALANCE
T
R
S
T
R
S
T
R
S
Insert cable wiring
1=ground
2=hot (+)
3=cold (-)
BALANCED
XLR FEMALE
RCA phono jacks
XLR MALE
2=hot (+)
1=ground
3=cold (-)
RCA PHONO CABLE
Sleeve=ground
Ring=cold (-)
Tip=hot (+)
BALANCED
1=ground
2=hot (+)
3=cold (-)
2=hot (+)
1=ground
3=cold (-)
Sleeve=ground
Ring=cold (-)
Tip=hot (+)
BALANCED
BALANCED
BALANCED
XLR FEMALE
XLR MALE
BALANCED
UNBALANCED
Sleeve=ground
Ring=cold (-)
Tip=hot (+)
BALANCED
Sleeve=ground
Ring=cold (-)
Tip=hot (+)
BALANCED
UNBALANCED
adapter
UNBALANCED
INSTRUMENT CABLE
TRS JACK CABLE
MIC CABLE
TRS to XLR-F CABLE
TRS to XLR-M CABLE
TO
FROM
INPUT OUTPUT
2 Outputs to 1 Input
Y-Adapter
No !
1 Output to 2 Inputs
Y-Adapter
Yes
General
Wiring
Information
