Human Interface Module
3-8
PROGRAM AND DISPLAY MODES (continued)
ACTION
DESCRIPTION
HIM DISPLAY
or
SEL
Changing Digits ❏ 2. With Series A HIM software versions 3.00 and above, or Series B HIM
software version 1.01 and above, you have the ability to access and
modify each individual bit or digit.
Important: This procedure assumes the Password is not set, you have
already logged in, or the device has been set to Defaults.
a. Select a parameter with Increment (or Decrement) keys.
b. Press the SEL key to view the first bit. Pressing this key again will
move the cursor to the left one bit or digit.
Individual bits of a Read/Write parameter can be changed. Pressing the
SEL key will move the cursor (flashing character) one bit to the left.
That bit can then be changed by pressing the Increment/Decrement
keys. When the cursor is in the far right position, pressing the
Increment/Decrement keys will increment or decrement the entire
value.
Accel Time
99.9 Secs
Choose Group
Setup
Flashing = Modify
