Human Interface Module
3-17
PASSWORD MODE
ACTION
DESCRIPTION
HIM DISPLAY
or
or
Login
Modify
or
➀
Setting Password
SEL
❏ 1. The factory default password is 0 (which disables password protection). To
change the password and enable password protection, perform the
following steps.
a. From the Status Display, press Enter (or any key). “Choose Mode” will
be shown.
b. Press the Increment (or Decrement) key until “Password” is displayed.
c. Press Enter.
d. Press the Increment (or Decrement) key until “Modify” is displayed.
e. Press Enter. “Enter Password” will be displayed.
f. Press the Increment (or Decrement) key to scroll to your desired new
password. With Series A HIM software versions 3.00 and above or
Series B HIM software version 1.01 and above, the SEL key allows
each digit to be selected and changed individually.
g. Press Enter to save your new password.
h. Press Enter again to return to the Password Mode.
Choose Mode
Display
Choose Mode
Password
Password
Login
Choose Mode
Password
Enter Password
< 123>
Enter Password
< 0>
Password
Modify
➀ Login is used to enter the password for access to the Program, Control Logic, Clear
Fault Queue, and EEPROM modes.
