1336 PLUS II Firmware Download Module 11
18. If errors occurred in the transfer, the screen may display one of
the following:
• Error in Constant Block
• Error in Program Block
• Error in DSP Block
• Error in Text and Language Block
If errors are indicated, press the Enter key on the computer and
return to step 10 on page 5 to repeat the entire process from that
point.
19. If no errors have occurred . . .
A. Remove all power from the drive and wait 60 seconds for the
bus to discharge.
B. Remove the communications cable from the module and
computer. Remove the Flash Download Module by grasping
the 4 locking tabs, then squeeze the tabs and pull the module
towards you.
C. Remove jumper J20 (installed in step 4 on page 2) and place
in spare jumper location.
D. If a new DSP Main Block is included in the downloaded file
(check information recorded in step 9 on page 4), a DSP file
image resides in flash memory. However, this image will not
be downloaded to the DSP until jumper J14 is installed and
drive power is applied. If J14 is not installed, a DSP Protected
fault (F46) will occur on power-up.
Locate a spare jumper on the Main Control Board and install
it at J14 (see Figure 1).
E. Reinstall the HIM or communications option and the Control
Interface Board, if previously removed.
F. Apply power to the drive. One of the following conditions
should occur:
G. Use a felt tip pen to mark the new Software Revision number
on the Main Control Board label.
20. Download is complete! Place this document with your User
Manual for future reference.
Condition Action then . . .
Drive active. No faults. If J14 is installed Power down and remove J14. Procedure is complete
If J14 is Not installed Procedure is complete
EE Init or other EE fault
occurs
Use the HIM EEPROM Menu
to reset the drive to factory
defaults
If J14 is installed Power down and remove J14.
Procedure is complete
if J14 is Not installed Procedure is complete
DSP Protected (F46) fault Install jumper J14 Cycle power a second time. Power down and remove J14.
Process complete
HIM Continuously displays
“Connecting….Connecting….
Repeat entire procedure
