14 Rockwell Automation Publication 1606-RM055A-EN-P - December 2016
Basic Power Supply 5 A
EMC
EMC Immunity According to Generic Standards EN 61000-6-1 and EN 61000-6-2 Criterion
(1)
Electrostatic discharge EN 61000-4-2 contact discharge
air discharge
8 kV
8 kV
Criterion A
Criterion A
Electromagnetic RF field EN 61000-4-3 80 MHz-2.7 GHz 20V/m Criterion A
Fast transients (Burst) EN 61000-4-4 input lines
output lines
DC-OK signal
(coupling clamp)
4 kV
2 kV
2 kV
Criterion A
Criterion A
Criterion A
Surge voltage on input EN 61000-4-5 L ->N
L ->PE, N ->PE
2 kV
4 kV
Criterion A
Criterion A
Surge voltage on output EN 61000-4-5 + ->-
+/- ->PE
500V
1 kV
Criterion A
Criterion A
Surge voltage on DC-OK EN 61000-4-5 DC-OK signal… PE 1 kV Criterion A
Conducted disturbance EN 61000-4-6 0.15…80 M Hz 20V Criterion A
Mains voltage dips EN 61000-4-11 0% of 100V AC
40% of 100V AC
70% of 100V AC
0% of 200V AC
40% of 200V AC
70% of 200V AC
0V AC, 20 ms
40V AC, 200 ms
70V AC, 500 ms
0V AC, 20 ms
80V AC, 200 ms
140V AC, 500 ms
Criterion A
Criterion C
Criterion A
(2)
Criterion A
Criterion C
Criterion A
Voltage interruptions EN 61000-4-11 0% of 220V AC (=0V) 5000 ms Criterion C
Voltage sags SEMI F47 0706 dips on the input voltage according to SEMI F47 standard
80% of 208V AC (166V AC)
70% of 208V AC (146V AC)
50% of 208V AC (104V AC)
80% of 120V AC (96V AC)
70% of 120V AC (84V AC)
50% of 120V AC (60V AC)
1000 ms
500 ms
200 ms
1000 ms
500 ms
200 ms
Criterion A
Criterion A
Criterion C
Criterion A
Criterion A
Criterion C
Powerful transients VDE 0160 over entire load range 750V, 1.3 ms Criterion A
(1) Criterion A: Power supply shows normal operation behavior withing the defined limits.
Criterion C: Temporary loss of function is possible. Power supply can shut down and restart by itself. No damage or hazard for the
power supply occurs.
(2) Below 4.5 A, Criterion C for currents above 5 A.
EMC Emission According to Generic Standards: EN 61000-6-3, EN 610000-6-4
Conducted emission input lines EN 55011, EN 55022
FCC Part 15
CISPR 11, CISPR 22
Class B
Conducted emission output
lines
(1)
IEC/CISPR 16-1-2, IEC/CISPR 16-2-1 limits for DC power port according to EN
61000-6-3 not fulfilled
Radiated emission EN 55011, EN 55022 Class B
Harmonic input current EN 61000-3-2 Fulfilled for class A equipment
Voltage fluctuations, flicker EN 61000-3-3 Fulfilled
(2)
This device complies with FCC Part 15 rules. Operation is subjected to following two conditions: (1) this device cannot
cause harmful interference, and (2) this device must accept any interference received, including interference that can
cause undesired operation.
(1) For information only, not mandatory for EN 61000-6-3.
(2) Tested with constant current loads, non-pulsing.
