Rockwell Automation Publication 1606-RM055A-EN-P - December 2016 19
Basic Power Supply 5 A
Specifications
Attribute 1606-XLB120E Notes
Output voltage DC 24V
24…28V DC Adjustment range
Output for AC 110…120/
220…240V mains:
5.0...4.3 A
3.1...2.7 A
at 24…28V, <55 °C
at 24…28V, <70 °C
for AC 100/200V mains: 5.0...4.3 A
2.5...2.1 A
at 24…28V, <50 °C
at 24…28V, <70 °C
Output ripple < 100 mVpp 20 Hz to 20 MHz
AC Input voltage AC 100-120V/200-240V ±10% Auto-Select
Mains frequency 50…60 Hz ±6 %
AC Input current 1.72 A/1.05 A at 120/ 230V AC
Power factor 0.64/0.54 at 120/ 230V AC
AC Inrush current 22 A/33 A peak at 120/ 230V AC, 40 °C
Efficiency 91.2 /92.3% at 120/ 230V AC
Losses 11.6 W/10.0 W at 120/ 230V AC
Temp. range -10… +70 °C
(14… 158 °F)
operational
Derating 3 W/°C 55…70 °C (131… 158 °F)
(1)
(1) 50…70 °C (122…158 °F) for AC 100 V/ 200V mains
Hold-up time 51 ms/50 ms at 120/ 230V AC
Dimensions 39 x 124 x124 mm W x H x D
Weight 370 g/0.81 lb
