18 POINT I/O Dual Port EtherNet/IP Adapter
Publication 1734-IN040C-EN-P - December 2018
Power Supply
Attribute Value
Input voltage rating 24V DC @ 10A
Input voltage, range 10...28.8V DC
Field side power, max 24V DC @ 400 mA
Inrush current, max 6 A for 10 ms
Input overvoltage protection Reverse polarity protected
POINTBus output current, max 5V DC @ 0.8A
Interruption Output voltage stays within specifications when input drops out
for 10 ms @ 10V with max load
Ethernet Communication
Attribute Value
Ethernet communication rate 10/100 Mbits/s, half or full-duplex
Ethernet ports 2, configured as Embedded Switch
Ethernet network topologies supported Star, Tree, Daisy-chain/Linear, and Ring
Ethernet connectors RJ-45, Category 5
Ethernet cable Category 5:
shielded or unshielded
Ethernet wire connections, max See Wire Size
on page 19
General Specifications
Attribute Value
Indicators 3 red/green status indicators on CPU:
– Module status
– Network status (Ports 1 and 2 combined)
– POINTBus status
1 green/yellow status indicator on CPU:
– Network activity (Ports 1 and 2 combined)
2 green/yellow status indicators on base:
– Link 1 activity/status
– Link 2 activity/status
2 green power supply status indicators on DC-DC Converter:
– System power (5V DC to POINTBus Out)
– Field power (24V DC from Field In)
Power consumption, max 10.4 W @ 28.8V DC
Power dissipation, max 6.3 W @ 28.8V DC
