POINT I/O Dual Port EtherNet/IP Adapter 19
Publication 1734-IN040C-EN-P - December 2018
Input overvoltage protection Reverse polarity protected
Thermal dissipation, max 21.5 BTU/hr @ 28.8V DC
Isolation voltage 50V (continuous), Reinforced Insulation Type, between
all
circuits
Type tested @ 500V AC for 60 s
Field power supply 10...28.8V DC @ 10A
Field power output 10...28.8V DC @ 9A
Module input 10...28V DC @ 1000 mA
POINTBus output, max 5V DC @ 0.8A
Dimensions (HxWxD), approx. 76.2 x 73.0 x 133.4 mm (3.0 x 2.87 x 5.25 in.)
Enclosure type rating None (open-style)
Terminal base screw torque 0.8 Nm (7 lb-in)
Weight, approx. 0.28 Kg (0.62 lb)
Wiring category
(1)
(2)
1 – on power ports
1 – on communications ports
Wire Size Power connections:
0.34... 2.1 mm
2
(22...14 AWG) solid or stranded copper wire rated
@ 75 °C (167 °F) or greater, 1.2 mm (3/64 in.) insulation max or
90 °C (194 °F) for ControlLogix.
Ethernet wiring:
RJ45 connector according to IEC 60603-7, 2 or 4 pair Category 5e
min cable according to TIA 568-B.1 or Category 5 cable according
to ISO/IEC 24702.
North American temp code T4
ATEX Temp Code T4
(1)
Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and
Grounding Guidelines, publication 1770-IN041
.
(2)
Use this Conductor Category information for planning conductor routing as described in the appropriate System Level
Installation Manual.
At the end of its life, this equipment should be collected separately from any
unsorted municipal waste.
General Specifications
Attribute Value
