POINT I/O Dual Port EtherNet/IP Adapter 19
Publication 1734-IN041F-EN-P - May 2019
General Specifications
Attribute Value
Indicators 3 red/green status indicators on CPU:
– Module status
– Network status (Ports 1 and 2 combined)
– POINTBus status
1 green/yellow status indicator on CPU:
– Network activity (Ports 1 and 2 combined)
2 green/yellow status indicators on base:
– Link 1 activity/status
– Link 2 activity/status
2 green power supply status indicators on DC-DC Converter:
– System power (5V DC to POINTBus Out)
– Field power (24V DC from Field In)
Power consumption, max 10.4 W @ 28.8V DC
Power dissipation, max 6.3 W @ 28.8V DC
Input overvoltage protection Reverse polarity protected
Thermal dissipation, max 21.5 BTU/hr @ 28.8V DC
Isolation voltage 50V (continuous), Reinforced Insulation Type, between all
circuits
Type tested @ 500V AC for 60 s
Field power supply 10...28.8V DC @ 10 A
Field power output 10...28.8V DC @ 9 A
Module input 10...28V DC @ 1000 mA
POINTBus output, max 5V DC @ 0.8 A
Dimensions (HxWxD), approx. 76.2 x 73.0 x 133.4 mm (3.0 x 2.87 x 5.25 in.)
Enclosure type rating None (open-style)
Terminal base screw torque 0.8 Nm (7 lb-in)
Weight, approx. 0.28 Kg (0.62 lb)
Wiring category
(1)
(2)
1 – on power ports
1 – on communications ports
Wire Size Power connections:
0.34...2.1 mm
2
(22...14 AWG) solid or stranded copper wire rated
@ 75 °C (167 °F) or greater, 1.2 mm (3/64 in.) insulation max or
90
°C (194 °F) for ControlLogix®.
Ethernet wiring:
RJ45 connector according to IEC 60603-7, 2 or 4 pair Category 5e
min cable according to TIA 568-B.1 or Category 5 cable according
to ISO/IEC 24702.
North American temp code T4
ATEX Temp Code T4
