20 POINT I/O Dual Port EtherNet/IP Adapter
Publication 1734-IN041F-EN-P - May 2019
(1)
Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and
Grounding Guidelines, publication 1770-IN041.
(2)
Use this Conductor Category information for planning conductor routing as described in the appropriate System Level
Installation Manual.
At the end of its life, this equipment should be collected separately from any
unsorted municipal waste.
Power Supply
Attribute Value
Input voltage rating 24V DC @ 10 A
Input voltage, range 10...28.8V DC
Field side power, max 24V DC @ 400 mA
Inrush current, max 6 A for 10 ms
Input overvoltage protection Reverse polarity protected
POINTBus output current, max 5V DC @ 0.8 A
Interruption Output voltage stays within specifications when input drops out
for 10 ms @ 10V with maximum load
Ethernet Communication
Attribute Value
Ethernet communication rate 10/100 Mbits/s, half or full-duplex
Ethernet ports 2, configured as Embedded Switch
Ethernet network topologies supported Star, Tree, Daisy-chain/Linear, and Ring
Ethernet connectors RJ-45, Category 5
Ethernet cable Category 5:
shielded or unshielded
Ethernet wire connections, max See Wire Size
on page 19
