6 POINT I/O Input Modules
Publication 1734-IN051H-EN-E - April 2013
Before You Begin
You can use these Series C POINT I/O™ Input Modules with DeviceNet and PROFIBUS
adapters. If you are using RSLogix 5000 software, version 11 or higher, you can also use the
modules with ControlNet and Ethernet adapters.
Use this diagram to identify the external features of the module.
POINT I/O Input Module
Description Description
1 Module locking mechanism 6 Mounting base
2 Slide-in writable label 7 Interlocking side pieces
3 Insertable I/O module 8 Mechanical keying
4 Removable Terminal Block handle 9 DIN rail locking screw
5 Removable Terminal Block (RTB) 10 Module wiring diagram
