Rockwell Automation Publication 1734-UM001E-EN-P - July 2013
92 Install POINTBlock I/O Modules
DeviceNet Connector Wiring
1734D-IB16 POINTBlock 16 DC Input Modules
14 2
6
15 3
7
120V AC is supplied through the internal power bus.
Channel Input Terminal Return Voltage
DeviceNet
Connection
Red
White
Bare
Blue
Black
-V
+V
CAN - High
Shield
CAN - Low
42004
10’s Node Address Rotary Switch
1’s Node Address Rotary Switch
Module Status
Network Status
I/O status
