POINT I/O Output Module 19
Publication 1734-IN018A-EN-P - November 2004
Surge Transient
Immunity
IEC 61000-4-5:
±1 kV line-line(DM) and ±2 kV line-earth (CM) on power
and signal ports
Conducted RF Immunity IEC 61000-4-6:
10 Vrms with 1 kHz sine-wave 80% AM from 150 kHz to 80
MHz
Emissions CISPR 11
Group 1, Class A
Enclosure Type Rating None (open-style)
Conductors Wire Size
Category
14 AWG (2.5 mm
2
) - 22 AWG (0.25 mm
2
) solid or stranded
copper wire rated at 75 °C or greater
3/64 inch (1.2 mm) insulation maximum
2
2
Terminal Base Screw
Torque
7 pound-inches (0.8 Nm)
Field Wiring
Terminations
1734-OB2
0 - Output 0 1 - Output 1
2 - Output 0 3 - Output 1
4 - Common 5 - Common
6 - Supply 7 - Supply
1734-OB4
0 - Output 0 1 - Output 1
2 - Output 2 3 - Output 3
4 - Common 5 - Common
6 - Common 7 - Common
1734-OB8
0 - Output 0 1 - Output 1
2 - Output 2 3 - Output 3
4 - Output 4 5 - Output 5
6 - Output 6 7 - Output 7
Weight - Inperial
Metric
1734-OB2 - 1.15 oz
1734-OB4 - 1.17 oz
1734-OB8 - 1.25 oz
1734-OB2 - 32.60 grams
1734-OB4 - 33.17 grams
1734-OB8 - 35.4 grams
