Rockwell Automation Publication 1756-UM540E-EN-P - December 2017 127
Configure ControlLogix Analog I/O Modules Chapter 7
4. On the General tab, name the module.
Make sure that the Slot number in the configuration matches the physical
slot number of the chassis housing the module.
The Description field is optional.
5. Click OK to accept the module’s default configuration.
The rest of this section describes how to change module configuration to
work as needed in your system.
