Rockwell Automation Publication 1756-UM540E-EN-P - December 2017 183
Analog I/O Module Tag Definitions Appendix A
1756-IF8I Module Tags
This section describes the tags associated with the 1756-IF8I module.
Configuration Tags
The following table describes the Configuration tags associated with the
1756-IF8I module.
IMPORTANT
Each applications series of tags varies but no input module application
contains any tags that are not listed here.
Table 28 - 1756-IF8I Module - Configuration Tags
Tag Name Data Type Definition Valid Values
Ch[x].InputRange SINT Channel’s operating range. 0 = -10…10V
1 = 0…5V
2 = 0…10V
3 = 0…20 mA (default)
Ch[x].NotchFilter SINT Notch Filter removes line noise for the channel.
There is a relationship between this setting and the RPI
setting. For more information on Notch Filter, see page 43
.
0 = 10 Hz
1 = 50 Hz
2 = 60 Hz (default)
3 = 100 Hz
5 = 1000 Hz
6 = 20 Hz
7 = 15 Hz
8 = 500 Hz
9 = 5000 Hz
10 = 5 Hz
Ch[x].AlarmDisable BOOL Disables all alarms on the module. 0 = Enabled
1 = Disabled (default)
Ch[x].ProcessAlarmLatch BOOL Latches Process alarms.
If this tag is set to latch the process alarms, the
I:Ch[x].LLAlarm, I:Ch[x].LAlarm, I:Ch[x].HAlarm or
I:Ch[x].HHAlarm tags do not clear until explicitly
unlatched.
0 = Latching disabled (default)
1 = Latching enabled
Ch[x].RateAlarmLatch BOOL Latches the Ramp alarm.
If this tag is set to latch the ramp alarm, the
I:Ch[x].RampAlarm tag does not clear until explicitly
unlatched.
0 = Latching disabled (default)
1 = Latching enabled
Ch[x]. Disable BOOL Disables the channel. 0 = Enabled (default)
1 = Disabled
Ch[x].Sourcing BOOL When in current mode, indicates if channel is Sinking or
Sourcing.
0 = Sinking (default)
1 = Sourcing
Ch[x].SynchronizeSampling BOOL Determines if the sampling of the channel is synchronized
with other modules configured as synchronized.
0 = Not synchronized (default)
1 = Synchronized
Ch[x].DigitalFilter INT Time Constant for First Order Lag firmware filter. 0…32,767 ms
(0 = default)
Ch[x].RateAlarmLimit REAL Rate of change in Engineering Units/Second
If the absolute value of the change between samples
divided by the sample time exceeds this value, the
I.Ch[x].RateAlarm tag is sets.
Any positive value
0.0 = default (This value represents
no change between samples.)
