Chapter 7 Configure ControlLogix Analog I/O Modules
Create a New Module
After you create a Logix Designer application project, complete the following
steps to create a module in the project.
1. Right-click I/O Configuration and choose New Module.
2. Select the module and click Create.
3. Click OK to accept the default major revision.
The New Module dialog box appears.
TIP
You can verify the module’s revision in RSLinx® Classic software.
