78 Rockwell Automation Publication 1756-UM540E-EN-P - December 2017
Chapter 4 Temperature-sensing Analog Modules
Cold Junction Offset Option
The Cold Junction Offset box on the Module Properties Configuration Tab lets
you make module-wide adjustments to cold junction compensation values. The
single Cold Junction Offset affects all channels equally. If you know that your
cold junction compensation values are consistently inaccurate by some level, for
example, 1.2 °C, type the value into the box to account for this inaccuracy.
Cold Junction temperatures are always reported as Celsius temperature units,
and, offset values are always set in Celsius temperature units.
You cannot change the temperature units.
