14 Rockwell Automation Publication 1756-UM058G-EN-P - November 2012
Chapter 1 What Are ControlLogix Digital I/O Modules?
I/O Modules in the
ControlLogix System
ControlLogix modules mount in a ControlLogix chassis and require either a
removable terminal block (RTB) or a Bulletin 1492 wiring interface module
(IFM)
(1)
to connect all field-side wiring.
Before you install and use your module, you must do the following:
• Install and ground a 1756 chassis and power supply. To install these
products, refer to the publications listed in Additional Resources
on
page 12.
• Order and receive an RTB or IFM and its components for your
application.
(1) The ControlLogix system has been agency certified using only the ControlLogix RTB catalog numbers 1756-TBCH, 1756-TBNH,
1756-TBSH, and 1756-TBS6H. Any application that requires agency certification of the ControlLogix system using other wiring
termination methods may require application-specific approval by the certifying agency.
RTBs and IFMs are not included with your module purchase. See page 116 for
RTBs and page 239
for IFMs.
Table 1 - ControlLogix Digital I/O Modules
Cat. No. Description Page
1756-IA8D 79…132V AC 8-point diagnostic input module 139
1756-IA16 74…132V AC 16-point input module 139
1756-IA16I 79…132V AC 16-point isolated input module 140
1756-IA32 74…132V AC 32-point input module 141
1756-IB16 10…31.2V DC 16-point input module 142
1756-IB16D 10…30V DC diagnostic input module 143
1756-IB16I 10…30V DC 16-point, isolated input module 144
1756-IB16IF 10…30V DC,16-point, isolated, fast peer control input module 145
1756-IB32 10…31.2V DC 32-point input module 146
1756-IC16 30…60V DC 16-point input module 147
1756-IG16 Transitor-transitor logic (TTL) input module 148
1756-IH16I 90…146V DC 16-point isolated input module 149
1756-IM16I 159…265V AC 16-point isolated input module 150
1756-IN16 10…30V AC 16-point input module 150
1756-IV16 10…30V DC 16-point sourcing current input module 151
1756-IV32 10…30V DC 32-point sourcing current input module 152
1756-OA8 74…265V AC 8-point output module
153
1756-OA8D 74…132V AC 8-point diagnostic output module 154
1756-OA8E 74…132V AC 8-point electronically-fused output module 155
1756-OA16 74... 265V AC 16-point output module 156
1756-OA16I 74…265V AC 16-point isolated output module 157
1756-OB8 10…30V DC 8-point output module 158
1756-OB8EI 10…30V DC 8-point electronically-fused, isolated output module 159
1756-OB8I 10…30V DC 8-point isolated output module 160
1756-OB16D 19.2…30V DC 16-point diagnostic output module 161
