Allen-Bradley 1769-OF8C User Manual

18 Compact 1769-OF8C Analog Output Module
Publication 1769-IN065B-EN-P - September 2005
Local:1:C.Ch1En BOOL Decimal
+ Local:1:C.Ch1Range SINT Decimal
+ Local:1:C.Ch1DataFormat SINT Decimal
+ Local:1:C.Ch1FaultValue INT Decimal
+ Local:1:C.Ch1ProgValue INT Decimal
+ Local:1:C.Ch1LClampValue INT Decimal
+ Local:1:C.Ch1HClampValue INT Decimal
+ Local:1:C.Ch1RampRate INT Decimal
Tag Name To Select
Make These Bit Settings
(1)
15-8 7 6 5 4 3 2 1 0
Ch#ProgToFaultEn Enable 1
Disable 0
Ch#HoldForInit Enable 1
Disable 0
Ch#ProgMode Enable 1
Disable 0
Ch#FaultMode Enable 1
Disable 0
Ch#RampEn Enable 1
Disable 0
Ch#AlarmLatchEn Enable 1
Disable 0
Ch#OverRangeInterruptEn Enable 1
Disable 0
Ch#UnderRangeInterruptEn Enable 1
Disable 0
Ch#En Enable 1
Disable 0
Ch#Range 0…20 mA dc 0
4…20 mA dc 1
Ch#DataFormat Raw/proportional
counts
0 0
Engineering units 0 1
Scaled for PID 1 0
Percent range 1 1
(1)
All bit positions left blank in table must be set to 0.
