Publication 1794-6.5.12 - November 1997
Chapter
1
Overview of FLEX I/O and Your
Thermocouple/RTD/mV Input Module
What This Chapter
Contains
Read this chapter to familiarize yourself with the 1794-IRT8 module.
What the
Thermocouple/RTD/mV
Input Module Does
The 1794-IRT8 module accepts up to 8 thermocouple or RTD inputs. The
inputs are nonisolated and are selected with analog multiplexers which
have a common-mode input range of ±4 volts. The inputs will accept a
millivolt or resistive input. Default input spans are –40.00mV to
+100.00mV or 0.00 to 500.00 ohms. Fault Indicators are located on the
field side.
No switches or jumpers are used on the TC/RTD Input module. The
Inputs have both fixed hardware filters and selectable firmware digital
filters.
How TC/RTD/mV Modules
Communicate with
Programmable Controllers
FLEX I/O Thermocouple/RTD/mV modules are block transfer modules
that interface analog signals with any Allen-Bradley programmable
controllers that have block transfer capability. Block transfer
programming moves input or output data words between the module’s
memory and a designated area in the processor data table. Block transfer
programming also moves configuration words from the processor data
table to module memory.
The adapter/power supply transfers data to the module (block
transfer write) and from the module (block transfer read) using BTW and
BTR instructions in your ladder diagram program. These instructions let:
the adapter obtain input or output values and status from the module
you establish the module’s mode of operation.
The illustration describes the communication process.
For information on See page
What the Thermocouple/RTD/mV Input Module Does. . . . . . . . . 1-1
How the module communicates . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Module features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
