Allen-Bradley 2097 series User Manual

Bulletin 2097 AC Line Filters 7
Publication 2097-IN003D-EN-P - November 2011
AC Line Filter Dimensions
Mounting dimensions for side and rear-mount AC line filters.
Figure 2 AC Line Filter (side-mount) Dimensions Catalog Numbers 2097-F1 and 2097-F2
Figure 3 AC Line Filter (rear-mount) Dimension Catalog Numbers 2097-F4, 2097-F5, and
2097-F6
35.8
(1.41)
33 0
(1.30)
149.9
(5.90)
165.6
(6.52)
Dimension are in mm (in.).
This connector comes prewired to
the AC line filter.
4.1
(0.16)
219.1
(8.62)
4.6 ø
(0.18)
4.6
(0.18)
68.6
(2.70)
48.0
(1.89)
38.1
(1.50)
15.2
(0.60)
211.0
(8.31)
Dimension are in mm (in.).
This connector comes prewired to
the AC line filter.
Allen-Bradley 2097-F1

Allen-Bradley 2097 series Specifications

General

Brand	Allen-Bradley
Model	2097 series
Category	Servo Drives
Language	English
