Chapter 1 Start
CE Requirements - System with LIM
To meet CE requirements when your Kinetix 7000 system includes the line
interface module (LIM), follow all the requirements as stated in CE
Requirements - System without LIM on page 19
and these additional
requirements that also apply to the AC line filter:
• Install the LIM, 2094-XL75S-Cx or 2094-BL50/75S, and line filter
(2090-XXLF-TCxxx) as close to the Kinetix 7000 drive as possible.
CE Requirements - System with DC Common Bus through 8720MC-RPS
To meet CE requirements when your Kinetix 7000 system includes a common
DC bus with an 8720MC-RPS, follow all the requirements as stated in the CE
Requirements - System without LIM on page 19
, the recommended installation
and wiring in the 8720MC Regenerative Power Supply Reference Manual,
publication 8720MC-RM001
, and these additional requirements:
• Install a three-phase line filter on the AC input power line of the RPS as
indicated in Interconnect Diagrams beginning on page 161
.
• Install a single-phase line filter when attaching an AC line input to the
RPS MC1/2 circuit as indicated in the Interconnect Diagrams beginning
on page 161
.
The full rated current on the AC input line should not exceed that of the line
interface module.
Catalog numbers 2094-XL75S-Cx or 2094-BL50S for 2099-BM06-S and
2099-BM07-S Kinetix 7000 drives, or 2094-BL75S for 2099-BM08-S Kinetix
7000 drives.
CE requires use of a grounded secondary or source with a 2099-BMxx-S
drive.
Never use a LIM in an ungrounded input, due to the potential for high line-
to-neutral voltages damaging components within the line filter.
