Allen-Bradley 20A Installation Instructions

206 Rockwell Automation Publication 750-IN001P-EN-P - April 2017
Chapter 4 Power Wiring
Figure 111 - Option P3 or P5 Disconnect and Option P11 Input Contactor
(only floor mount Frame 8)
No. Name Description
1 R/L1, S/L2, T/L3 Three-phase input power connection.
2 PE Three-phase input ground.
3 U/T1, V/T2, W/T3 Motor connection that is made at drive power bus. See page 164
.
U / T1
V / T2
W / T3
3
2
1
Drive
Motor
P3 or P5
P11
