78 Rockwell Automation Publication 750-IN001P-EN-P - April 2017
Chapter 3 Lift and Mount the Drive
Figure 43 - IP54, NEMA 12, MCC Style Cabinet, Floor Mount Frame 8 (Enclosure Codes K and Y)
IP54, UL Type 12, MCC Style Cabinet, Floor Mount Frame 8 (Enclosure Code J)
M12 (1/2 in.) Property Class 8.8 anchor hardware is recommended
to fasten the drive cabinet through its internal mounting angle to the
foundation. Anchor bolts can be pre-located and embedded in the
foundation before instillation.
2477
(97.5)
800
(31.5)
600
(23.6)
2300
(90.6)
898
(35.4)
240
(9.4)
1374
(54.1)
300
(11.8)
531
(20.9)
ø18.0
(0.71)
742
(29.2)
43
(1.7)
69
(2.7)
76
(3.0)
1
2
2
3
4
680
(26.8)
547
(21.5)
1464
(57.6)
127
(5.0)
292
(11.5)
440
(17.3)
127
(5.0)
76
(3.0)
No. Description
1 Power wiring conduit plates.
2 Control wiring conduit plates.
3 Optional HIM.
4 Recommended three-hole anchoring.
Bottom
Bottom
Top
To Next Page
