152 Rockwell Automation Publication 5069-UM004A-EN-P - April 2019
Chapter 6 Configure a Standard Module
5. At the warning dialog box, click Yes.
6. Close the Select Module Type dialog box.
To add additional local I/O modules with this method, complete one of the
following:
If you cleared the Close on Create checkbox when you created the first
I/O module, repeat steps
36.
If you did not clear the Close on Create checkbox when you created the
first I/O module, repeat steps
26.
TIP If you inhibit the module connection, you must remember to
uninhibit the connection later.
