Allen-Bradley A Series User Manual

4 DeviceNet ArmorBlock™ Network Powered 16-input Module
Publication 1732D-IN007B-EN-E - November 2011
About the Module
The DeviceNet 1732D ArmorBlock I/O family consists of standalone 24V DC I/O
modules that communicate via the DeviceNet network. The sealed IP67 housing of these
modules requires no enclosure. Note that environmental requirements other than IP67
may require an additional appropriate enclosure. I/O connectors are sealed M12-style.
The 1732D-IBDPM12MND module is shown here.
DeviceNet ArmorBlock Network Powered 16-input Module
Ground Conductors
Conductor Description
Protective earth Provides the grounding of field devices and is internally
connected to each Pin 5 of the M12 I/O connectors.
I - 1
I - 2
I - 3
I - 0
I - 4
I - 5
I - 6
I - 7
I - 14
I - 13
I - 12
I - 15
I - 11
I -10
I - 9
I - 8
X10 X1
D
N
e
t
In
NETMOD
2
4
8
66
00
8
2
4
44773
12 mm I/O
connectors
Mini-style
DeviceNet
connectors
Node address
12 mm I/O
connectors
Protective
earth
