POINT I/O Input Module 15
Publication 1734-IN051D-EN-P - April 2004
Network Status
Off Device is not on-line
- Device has not completed dup_MAC_id test.
- Device not powered - check module status indicator
Flashing Green Device is on-line but has no connections in the
established state.
Green Device on-line and has connections in the established
state.
Flashing Red One or more I/O connections in timed-out state
Red Critical link failure - failed communication device.
Device detected error that prevents it communicating on
the network.
Flashing Red/Green Communication faulted device - the device has detected
a network access error and is in communication faulted
state. Device has received and accepted an Identify
Communication Faulted Request - long protocol
message.
Indication Probable Cause
I/O Status
Off Input is in the off-state
Yellow Input is in the on-state
Indication Probable Cause
