DC-UPS - 24V, 20 A, 480 W Reference Manual
Electromagnetic
Compatibility
The DC-UPS is suitable for applications in industrial environment and in
residential, commercial, and light industry environment without any
restrictions.
All tests are performed in power supply and battery mode.
Attributes Standards Values
Criteria
(1)
(1) Criterion A: The device shows normal operation behavior within the defined limits.
Criterion B: The device operates continuously during and after the test. During the test, minor temporary
impairments may occur. If they do occur, the device corrects them.
Criterion C: Temporary loss of function is possible. The device may shut down. If it shuts down, it then restarts by
itself. No damage or hazards for the device occur.
Electrostatic discharge
(2)
(2) Chassis ground connection earthed (grounded)
EN 61000-4-2
Contact discharge 8 kV Criterion A
Air discharge 15 kV Criterion A
Electromagnetic RF field EN 61000-4-3 80 MHz…2.7 GHz 10V/m Criterion A
Fast transients (Burst) EN 61000-4-4
Input lines 2 kV Criterion A
Output lines 2 kV Criterion A
Signals
(3)
(3) Tested with coupling clamp
2 kV Criterion A
Surge voltage on input EN 61000-4-5
L  N1 kVCriterion A
N / L  PE 2 kV Criterion A
Surge voltage on output EN 61000-4-5
+  -1 kVCriterion A
+ / -  PE 2 kV Criterion A
Surge voltage on battery
and center-tap
EN 61000-4-5
+  -
(4)
(4) Not relevant due to short wire length
Criterion A
+ /-chassis ground 1 kV Criterion A
Surge voltage on inhibit
input, ready-, buffering and
replace battery contacts
EN 61000-4-5
signals  chassis
ground
1 kV Criterion A
Surge voltage on
temperature sensor
EN 61000-4-5
signals  chassis
ground
1 kV Criterion A
Conducted disturbance EN 61000-4-6 0.15…80 MHz 10V Criterion A
