Chapter 1 Hardware Overview
Status Indicator
State During Normal Operation During Firmware Update or
Program/Data Transfer
Off No power applied to device, or in Fault
mode
No power applied to device, or in Fault
mode
Solid green Device operating normally Program transfer successful
Flashing green Operating System error Firmware update in progress
Micro810 Controllers
Catalog Number Power Inputs Outputs Analog In 0…10V
(shared with DC In)
120V AC 240V AC 12…24V DC /V AC Relay 24 V DC SRC
2080-LC10-12QWB 24V DC 8 4 4
2080-LC10-12AWA 120…240V AC 8 4
2080-LC10-12QBB 12…24V DC 8 4 4
2080-LC10-12DWD 12V DC 8 4 4
