36 Rockwell Automation Publication 2080-UM001B-EN-E - November 2011
Appendix A Specifications
Micro800 Programmable Controller External AC Power Supply
General
Attribute Value
Dimensions, HxWxD 90 x 45 x 80 mm (3.55 x 1.78 x 3.15 in.)
Shipping weight 0.34 kg (0.75 lb)
Supply voltage range
(1)
(1) Any fluctuation in voltage source must be within 85V...264V. Do not connect the adapter to a power source that has
fluctuations outside of this range.
100V…120V AC, 1A
200…240V AC, 0.5A
Supply frequency 47…63 Hz
Supply power 24V DC, 1.6 A
Inrush current, max 24A @ 132V for 10 ms
40A @ 263V for 10 ms
Power consumption (Output
power)
38.4W @ 100V AC, 38.4W @ 240V AC
Power dissipation (Input
power)
45.1W @ 100V AC, 44.0W @ 240V AC
Isolation voltage 250V (continuous), Primary to Secondary: Reinforced Insulation Type
Type tested for 60s at 2300V AC primary to secondary and 1480V AC
primary to earth ground.
Output ratings 24V DC, 1.6A, 38.4W max.
Enclosure type rating Meets IP20
Wire size 0.32... 2.1 mm² (22...14 AWG) solid copper wire or
0.32... 1.3 mm² (22...16 AWG) stranded copper wire
rated at 90 °C (194 °F ) insulation max
Terminal screw torque 0.5…0.6 Nm (4.4…5.3 lb-in)
(using a Phillips-head or 2.5 mm (0.10in.) flat-blade screwdriver)
Wiring category
(2)
(2) Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and Grounding
Guidelines, publication 1770-4.1
.
2 – on power ports
Insulation stripping length 7 mm (0.28 in)
North American temp code T4A
