Rockwell Automation Publication 2080-UM001B-EN-E - November 2011 49
Troubleshooting Appendix D
0xF010 The user program contains a function/
function block that is not supported by
the Micro800 controller.
Perform the following:
• Modify the program so that all functions/function blocks are supported by the
Micro800 controller.
• Build and download the program using Connected Components Workbench.
• Put the Micro800 controller on Run mode.
0xF014 A memory module memory error
occurred.
Reprogram the memory module. If the error persists, replace the memory module.
0xF015 An unexpected software error occurred. Perform the following:
1. Cycle power on your Micro800 controller.
2. Build and download your program using Connected Components Workbench, and
then reinitialize any necessary data.
3. Start up your system.
See Wire Your Controller
on page 17.
0xF016 An unexpected hardware error occurred. Perform the following:
1. Cycle power on your Micro800 controller.
2. Build and download your program using Connected Components Workbench, and
then reinitialize any necessary data.
3. Start up your system.
See Wire Your Controller
on page 17.
0xF020 The base hardware faulted or is
incompatible with the Micro800
controller’s firmware revision.
Perform one of the following:
• Upgrade the Micro800 controller’s firmware revision using ControlFlash.
• Replace the Micro800 controller.
• Contact your local Rockwell Automation technical support representative for more
information about firmware revisions for your Micro800 controller. For more
information on firmware revision compatibility, go to
http://www.rockwellautomation.com/support/firmware.html
0xF021 The I/O configuration in the user program
is invalid or does not exist in the
Micro800 controller.
Perform the following:
• Verify that you have selected the correct Micro800 controller from the Device
Toolbox.
• Correct the plug-in I/O module configuration in the user program to match that of the
actual hardware configuration.
• Recompile and reload the program.
• Put the Micro800 controller on Run mode.
• If the error persists, be sure to use Connected Components Workbench programming
software to develop and download the program.
0xF022 The user program in the memory module
is incompatible with the Micro800
controller’s firmware revision.
Perform one of the following:
• Upgrade the Micro800 controller’s firmware revision using ControlFlash to be
compatible with the memory module.
• Replace the memory module.
• Contact your local Rockwell Automation technical support representative for more
information about firmware revisions for your Micro800 controller. For more
information on firmware revision compatibility, go to
http://www.rockwellautomation.com/support/firmware.html
List of Error Codes for Micro800 controllers
Error Code Description Recommended Action
