Rockwell Automation Publication 2080-UM005B-EN-E - March 2015 5
Hardware Overview Chapter 1
Ethernet port pin-to-pin connection
See Troubleshooting on page 123 for descriptions of ENET status indicator.
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
white-orange
orange
white-green
blue
white-blue
green
white-brown
brown
white-orange
orange
white-green
blue
white-blue
green
white-brown
brown
46223
