Allen-Bradley Micro820 User Manual

Rockwell Automation Publication 2080-UM005B-EN-E - March 2015 25
Install Your Controller Chapter 3
Panel Mounting Dimensions
Micro820 20-point controllers
2080-LC20-20AWB, 2080-LC20-20QWB, 2080-LC20-20QBB
2080-LC20-20AWBR, 2080-LC20-20QWBR, 2080-LC20-20QBBR
Connect the Controller to an
EtherNet/IP Network
46204
86 mm (3.39 in.)
100 mm
(3.94 in.)
WARNING: If you connect or disconnect the communications cable with
power applied to this module or any device on the network, an electrical
arc can occur. This could cause an explosion in hazardous location
installations.
Be sure that power is removed or the area is nonhazardous before
proceeding.

Allen-Bradley Micro820 Specifications

General

Processor	32-bit
Power Supply	24V DC
Programming Software	Connected Components Workbench
Series	Micro800
Mounting	DIN Rail
Memory	Embedded
Expansion	Yes
Controller Type	Programmable Logic Controller (PLC)
Communication	Ethernet/IP
Programming Language	Ladder Diagram, Function Block Diagram, Structured Text
I/O	Embedded
