Allen-Bradley Micro820 User Manual

Rockwell Automation Publication 2080-UM005B-EN-E - March 2015 23
Chapter 3
Install Your Controller
This chapter serves to guide the user on installing the controller. It includes the
following topics.
Controller Mounting
Dimensions
Mounting dimensions do not include mounting feet or DIN rail latches.
Topic Page
Controller Mounting Dimensions 23
Connect the Controller to an EtherNet/IP Network 25
Module Spacing 24
DIN Rail Mounting 24
Panel Mounting 24
Panel Mounting Dimensions 25
Install the microSD Card 26
Install the 2080-REMLCD Module 27
46205
Measurements in millimeters (inches)
104 (4.09)
75 (2.95)
90 (3.54)

Allen-Bradley Micro820 Specifications

General

Processor	32-bit
Power Supply	24V DC
Programming Software	Connected Components Workbench
Series	Micro800
Mounting	DIN Rail
Memory	Embedded
Expansion	Yes
Controller Type	Programmable Logic Controller (PLC)
Communication	Ethernet/IP
Programming Language	Ladder Diagram, Function Block Diagram, Structured Text
I/O	Embedded
